PVC INSULATED COPPER ARMOURED CABLES 10.00MM² (6941X)

WSG-19400

PVC INSULATED COPPER ARMOURED CABLES 10.00MM² (6941X)



DESCRIPTION:

PVC Insulated, PVC Taped, Steel Wire Armoured and PVC Sheathed.

Multicore Control Cables with Stranded Copper conductors

Ref. 6941X

Standard: BS 6346, KS 04-194.

Single Core Cables with a Voltage rating: 600/1000V.

Application: Electricity supply and industrial wiring for remote control and telemetry circuits etc. Suitable; laid direct in the ground, or in ducts, clipped to surface, on trays or in free air. May be embedded in concrete.

Construction: Multi-core cables. Stranded or solid plain copper conductors, PVC insulated, cores laid up, extruded PVC bedding, galvanized steel wire armoured and PVC sheathed.

Core colours:

Single core: Red or Black

Two core: Red and Black

Three core: Red, Yellow and Blue

Four core: Red, Yellow, Blue and Black

Five core: Red, Yellow, Blue, Black, Green/Yellow

Sheath colour: Black.

Other colours available to order.



Please note that the below price is quoted per meter.

Maximum conductor temperature: 70°C
